Barrier Strip Terminal Block 8A 1.31mm2 1 Row(s)
| Weight | 0.05 kg |
|---|---|
| Manufacturer | TE CONNECTIVITY/AMP BRAND |
| Part Number | 1-2350398-4 |
| PRC | AMP |
| Centerline (Pitch) | .137 in 3.5 mm |
| Circuit Application | Signal |
| Connector & Contact Terminates To | Wire & Cable |
| Connector System | Wire-to-Board |
| Contact Base Material | Phosphor Bronze |
| Contact Current Rating (Max) | 8:00 AM |
| Contact Mating Area Plating Material | Tin |
| Housing Material | PA 66 |
| Number of Positions | 14 |
| Number of Rows | 1 |
| Operating Temperature Range | -40 – 105 °C -40 – 221 °F |
| Operating Voltage | 150 VAC |
| Packaging Method | Box |
| Primary Product Color | Green |
| Termination Method to Wire & Cable | Push-in Spring Terminal |
| Wire Size | 24 – 16 AWG .05 – 1.31 mm² |
