Rack and Panel Connector 5 Contact(s) Male Crimp
| Weight | 0.05 kg |
|---|---|
| Manufacturer | TE CONNECTIVITY / DEUTSCH |
| Part Number | ABC03N-20P |
| PRC | DE |
| Circuit Application | Power & Signal |
| Connector & Contact Terminates To | Wire & Cable |
| Connector & Housing Type | Receptacle |
| Connector Mounting Type | Panel Mount |
| Connector System | Wire-to-Wire |
| Contact Current Rating (Max) | 7.5 A |
| Contact Retention Within Housing | With |
| Contact Size | Size 20 |
| Contact Type | Pin |
| Housing Material | Composite |
| Mating Alignment | With |
| Mating Alignment Type | Keyed |
| Mating Retention Type | Latch |
| Number of Positions | 5 |
| Number of Rows | 2 |
| Operating Temperature Range | -65 – 175 °C -85 – 347 °F |
| Sealable | Yes |
| Wire Size | 24 – 20 AWG |
